 Song Woei Industry Co., Ltd บริษัท ซ่ง เว้าย อินดัสทรี จำกัด ก่อตั้งขึ้นในปี พ.ศ. 2532 เราเป็นผู้ผลิตชิ้นส่วนอัตโนมัติระดับมืออาชีพในไต้หวัน เราผลิตชุดแกนหมุนเจาะอัตโนมัติคุณภาพสูง ชุดแกนหมุนต๊าป ชุดแกนหมุนความแม่นยำสูง หัวแกนหมุนหลายแกน ชุดสไลด์สกรูหลากหลายชนิด ชุดสไลด์ไฮดรอลิก ชุดสไลด์เซอร์โวพิเศษ ดัชนีลูกเบี้ยวเกียร์ลูกกลิ้ง และกระบวนการผลิตอัตโนมัติความแม่นยำสูงอื่นๆ พร้อมการออกแบบส่วนประกอบ
ตลอดระยะเวลา 20 ปี ทีมงานของซ่ง เว้าย ได้ค้นคว้าและพัฒนานวัตกรรมเพื่อเสริมสร้างโครงสร้างการจัดการ สะสมเทคโนโลยีการพัฒนาที่แข็งแกร่ง ความสามารถในการติดต่อสื่อสารที่รวดเร็ว ประสบการณ์อันยาวนาน และการออกแบบที่ทำงานร่วมกันอย่างมีประสิทธิภาพ พร้อมบริการที่ดีที่สุด เรานำเสนอผลิตภัณฑ์ที่มีประสิทธิภาพสูงสุดให้กับเครื่องจักรแปรรูปทุกประเภท เช่น เครื่องจักรเฉพาะทางสำหรับวาล์ว สกรู และชิ้นส่วน อุปกรณ์ป้อนอัตโนมัติ เครื่องจักรแปรรูปทุติยภูมิ เครื่องประกอบอัตโนมัติ เครื่องจักรอาหารและบรรจุภัณฑ์ ระบบผลิตภัณฑ์แปรรูปอัตโนมัติแบบบูรณาการเหล่านี้ไม่เพียงแต่ช่วยให้ลูกค้าของเราสร้างประโยชน์สูงสุดด้านการผลิต แต่ยังสร้างชื่อเสียงที่ดี แม้กระทั่งการเป็นผู้นำในตลาด
เพื่อตอบสนองต่อการใช้งานผลิตภัณฑ์อย่างแพร่หลายในอุตสาหกรรมเครื่องจักรและอุปกรณ์อัตโนมัติที่หลากหลาย องค์กรต่างๆ จึงเติบโตอย่างต่อเนื่อง แสดงให้เห็นถึงศักยภาพที่ไร้ขีดจำกัด ในปี 2552 ซ่งเวาอีได้ย้ายไปยังโรงงานแห่งใหม่เพื่อขยายการดำเนินงาน สภาพแวดล้อมการทำงานที่กว้างขวางขึ้น ประกอบกับระบบดาวเทียมที่เชื่อถือได้และการควบคุมคุณภาพอย่างเข้มงวด ไม่เพียงแต่ผลิตภัณฑ์จะมีความสมบูรณ์มากขึ้นเท่านั้น แต่ยังส่งมอบได้อย่างรวดเร็ว นอกจากนี้ เรายังมุ่งมั่นที่จะพัฒนาโมดูลาร์ให้มีความสมบูรณ์แบบสูง และมุ่งหวังที่จะมอบผลิตภัณฑ์และบริการที่สามารถแข่งขันได้ให้กับลูกค้า
เป็นเวลานานที่เราปฏิบัติต่อลูกค้าทุกคนในฐานะพันธมิตรที่ดี และนำเสนอผลิตภัณฑ์ที่ดีที่สุดพร้อมบริการที่ดีที่สุดเพื่อตอบสนองความต้องการของลูกค้า ทีมงานซ่งเวาอีหวังเป็นอย่างยิ่งว่าเราจะร่วมมือกับคุณในอนาคตอันใกล้นี้
มาร่วมกับเราและเติบโตไปด้วยกัน!!
สายด่วน 098-4288648
โทร : คุณภูรินทร์ 0984288648
Drilling Spindle Units-SWD3-60
Drilling Spindle Units-SWD4-80
Drilling Spindle Units-SWD5-85
Drilling Spindle Units-SWD6-130
Drilling Spindle Units-SWD8-150 / SDW8-200
Drilling & Boring Spindle Units-SWD65-100
Drilling & Boring Spindle Units-SWD9-110
Drilling Spindle Units
SWD3-60
|
MODEL
|
SWD3-60
|
|
Drilling Capacity
|
φ6(S45C)
|
|
Max. Stroke
|
60mm
|
|
Max.revolution/Minute
|
6000r.p.m
|
|
Working pressure
|
Pneumatic:3~7kg/Cm2
|
|
Hydraulic:10-15 kg/ cm2
|
|
Cylinder Diameter
|
φ50mm
|
|
Cylinder Area
|
Forward:12.6 cm2
|
|
Backward:7.1 cm2
|
|
Power
|
0.37KW-220V(380V)-60HZ(50HZ)-3∅
|
|
Transmission Pulley
|
PJ-200-5
|
|
Net Weight
|
21kg
|
|
Consumables
|
|
Spindle Bearing
|
6002ZZ*4
|
|
Pulley Bearing
|
6002ZZ*3
|
|
Oil Seal for Piston
|
Pneumatic:APG-40*50*6.5-2
|
|
Wear Ring
|
AGE-50×46×6-1
|
|
Oil Seal for Piston
|
Hydraulic:APS-326-2
|
|
Oil Seal For Spindle
|
TC-22×30×7-1
|
|
Oil Seal For Front cover(Pneumatic)
|
ADH-40×48×6.5-1 AG-45-1 AP-40-1
|
|
Oil seal For Front cover(Hydraulic)
|
TC-40×50×8-1 AG-45-1 AP-40-1
|
|
Oil Seal For Rear Cover(Pneumatic)
|
ADH-30×38×6.5-1 AG-40-1 AP-30-1
|
|
Oil Seal For Rear Cover(Hydraulic)
|
TC-40×50×8-1 AG-45-1 AP-40-1
|
|
Self-lubricating bearing
|
DU-30×10-1
|
Drilling Spindle Units
SWD4-80
SWD4-80
SPECIFICATIONS
|
Model
|
SWD4-80
|
|
Drilling Capacity
|
φ6(S45C)
|
|
Max. Stroke
|
80mm
|
|
Max.revolution/Minute
|
8000r.p.m
|
|
Working Pressure
|
Pneumatic:3~7kg/cm2
|
|
Hydraulic:10-15 kg/ cm2
|
|
Cylinder Diameter
|
φ50mm
|
|
Cylinder Area
|
Forward:12.6 Cm2
|
|
Backward:7.1 Cm2
|
|
Power
|
0.37KW-220V(380V)-60HZ(50HZ)-3∅
|
|
Transmission Pulley
|
PJ-200-5
|
|
Net Weight
|
24kg
|
|
Consumables
|
|
Spindle Bearing
|
6002ZZ*4
|
|
Pulley Bearing
|
6002ZZ*3
|
|
Oil Seal for Piston
|
Pneumatic:APG-40*50*6.5-2
|
|
Wear Ring
|
AGE-50×46×6-1
|
|
Oil Seal for Piston
|
Hydraulic:APS-326-2
|
|
Oil Seal For Spindle
|
TC-22×30×7-1
|
|
Oil Seal For Front cover(Pneumatic)
|
ADH-40×48×6.5-1 AG-45-1 AP-40-1
|
|
Oil seal For Front cover(Hydraulic)
|
TC-40×50×8-1 AG-45-1 AP-40-1
|
|
Oil Seal For Rear Cover(Pneumatic)
|
ADH-30×38×6.5-1 AG-40-1 AP-30-1
|
|
Oil Seal For Rear Cover(Hydraulic)
|
TC-40×50×8-1 AG-45-1 AP-40-1
|
|
Self-lubricating bearing
|
DU-30×10-1
|
สายด่วน 098-4288648
โทร : คุณภูรินทร์ 0984288648
Mandrel Type (S)
?Output shaft is round with key.
?Connected with coupling or keyway.
?The remedy of output shaft diameter is h6.
? Apply in the periodic conveyer, or through the gear, timing belt, chain transmits to the periodic mechanism.
CHARACTER
For the automatic and laborsaving the automations or sole-machine adopt with cam indexes are popular, in general assess the roller cam index are the most stable and confident.
1. The track of the cam are grinding by five axils CNC grinder, working smoothly, precisely orientation, no slide and deflections, no tolerance accumulation.
2. The cam are high precision, no clearance, accurate position (within ±30sec),low noise, because it have special acceleration rate curve so it can rotation in high speed driver divider smoothly over 6000rpm.
3. The cam made by high-grade alloy steel, the materials are very tenacity after heat-treating with carbon infiltration, The cam immersed in the oil with output shaft cam bearing, it can reduce scratch in high speed, keep the cam lift time up to 12,000hr.
4. The structures of the roller gear cam index are very simply, reliable and trouble free.
5. Assembly in any face, easy to use.
MAIN USE
Automatic assembling machine, process machine. Packaging machine, Filler& Capper. Food process machine, Pharmaceutical machine. Printing press, Pad Printer, Screen Printer, Hot Stamping and Hot Transfer machine. Ceramic Disc Capacitor Sorter, Label machine. Semi-conductor test and sorting machine. Periodic feeder in various industrial.
HOW TO PURCHASE
1. The diameter of in/output shaft
45D. 60D. 70D. 80D. 110D. 140D
2. The shape of output shaft
S (Mandrel Type) ? F (Flange Type)? FH (Hollow Flange Type)
3. The divisional of output shaft
2 . 3 . 4 . 5 . 6 . 8 . 10 . 12 . 16 . 20 . 24 . 30 . 36 . 48 . 60
4. Movement angle of input shaft
90 . 120 . 180 . 270 . 300 (Special angle designation was accepts)
5. Input cam shaft robate
R (Dextral Cam)?L (Sinistral Cam)?Do not consider if motor can reveres.
6. Curve of cam
a. Transfigure turn (Standard)
b. Transfigure echelon
c. Transfigure uniform velocity
7. Input shaft Selection
D : Bilateral input shaft
R : Rightwards mono-input shaft
L : Leftwards mono-input shaft
8. Installation face of output shaft
reference (Fig. 3)
|
Input and output shaft rotate direct (Fig.1)
|
Select input shaft (Fig. 2)
|
| |
|
|
|
|
|
|
|
|
Select the position of set up surface. oil level. oil supply. Drain (Fig. 3)
|
| |
|
|
|
|
|
Table of Hollow Flange I.D.
|
|
Type
|
60D
|
70D
|
80D
|
110D
|
140D
|
|
LD.
|
φ16
|
φ25
|
φ30
|
φ38
|
φ50
|
| |
|
|
|
|
|
|
??????T?-T-108
??????T?-T-121
???A?-A-100 / A-124
RU-100 / RU-120 / RU-165 / RU-200 / RU-250 / RU-300
SPECIFICATIONS
|
Model
|
RU-100
|
RU-120
|
RU-165
|
RU-200
|
RU-250
|
RU-300
|
|
Collet
|
C-6, C-9
|
|
Max. Drilling Capacity (mm)
|
6/8
|
|
R.P.M.
|
1:1
|
|
Max. Range of Centers
|
100
|
120
|
165
|
200
|
250
|
300
|
|
Lowest Distance
|
18, 26
|
|
Spindle
|
2~6
|
2~6
|
2~10
|
4~12
|
4~12
|
Spindle Head Series > Adjustable Spindles Head
A-100 / A-124
SPECIFICATIONS
|
Model
|
A-100 (A-116)
|
A-124
|
A-121S
|
|
Collet
|
C-6
|
C-9, JT1
|
C-12, JT2
|
|
Max. Drilling Capacity (mm)
|
6
|
8
|
11
|
|
R.P.M.
|
1:1.35 (1:1)
|
1:1.3 (1:1)
|
1:1.3 (1:1)
|
|
Max. Range of Centers
|
100
|
124
|
124
|
|
Lowest Distance
|
18
|
26
|
28
|
|
Spindle
|
2~4
|
Spindle Head Series Adjustable Spindles Head
T-121
SPECIFICATIONS
|
Model
|
T-71
|
T-74
|
T-108
|
NT-108
|
T-121
|
T-121S
|
NT-121S
|
|
Collet
|
ND-1, NT-1
|
C-5
|
C-6, JT1
|
C-6
|
C-9, JT1
|
C-12
|
C-9, C-12
|
|
Max. Drilling Capacity
|
3
|
4
|
6
|
6
|
8
|
10
|
8, 10
|
|
R.P.M.
|
1:1
|
|
Max. Range of Centers
|
71
|
74
|
108
|
108
|
121
|
121
|
121
|
|
Lowest Distance
|
10
|
12
|
18
|
18
|
24
|
27
|
27
|
|
Spindle
|
2
|
Spindle Machines Series > Spindle
Boring & Milling Spindles Units-SW-20B
Boring & Milling Spindles Units-SW-30
Precision Spindles Units-SW-40G
Boring & Milling Spindles Units-SW-40 & SW-50
Boring & Milling Spindles Units-SW-40C
Boring & Milling Spindles Units-SW-40F
Boring & Milling Spindles Units-SW-60
Boring & Milling Spindles Units-SW-80
Boring & Milling Spindles Unit
Spindle Machines Series > Spindle
Boring & Milling Spindles Units
SW-85K
SW-85K
SPECIFICATIONS
|
Model
|
SW- 85K
|
|
Spindle Bearing
|
32216 / 32215 / 6215Z
|
|
Max. revolution/Minute
|
1200RPM
|
|
Rising Temperature
|
20?C
|
|
Max. Power
|
7.5KW(10HP)
|
|
Spindle Roundness
|
MAX?0.005mm
|
|
Lubrication
|
Grease
|
|
Net Weight
|
145kg
|
Spindle Machines Series > Spindle
Boring & Milling Spindles Units
SW-80
SW-80 / SW-80H
SPECIFICATIONS
|
Model
|
SW- 80
|
SW- 80H
|
|
Spindle Bearing
|
32216-2 / 6216Z-2
|
7216-4
|
|
Max. revolution/Minute
|
4000RPM
|
3000RPM
|
|
Rising Temperature
|
20?C
|
|
Max. Power
|
5.5KW(7.5HP)
|
|
Spindle Roundness
|
MAX?0.005mm
|
|
Lubrication
|
Grease
|
|
Net Weight
|
95kg
|
Spindle Machines Series > Spindle
Boring & Milling Spindles Units
SW-60
SW-60 / SW-60H
SPECIFICATIONS
|
Model
|
SW- 60
|
SW- 60H
|
|
Spindle Bearing
|
32216/6212Z-32211/6211Z
|
7212-2 7211-2
|
|
Max. revolution/Minute
|
1700RPM
|
4000RPM
|
|
Rising Temperature
|
20?C
|
|
Max. Power
|
3.7KW(5HP)
|
|
Spindle Roundness
|
MAX?0.005mm
|
|
Lubrication
|
Grease
|
|
Net Weight
|
60kg
|
Spindle Machines Series > Spindle
Boring & Milling Spindles Units
SW-40F
SW-40F / SW-40FH
SPECIFICATIONS
|
Model
|
SW- 40F
|
SW- 40FH
|
|
Spindle Bearing
|
322018/6208Z-32207/6207Z
|
7208-2 7207-2
|
|
Max. revolution/Minute
|
2500RPM
|
8000RPM
|
|
Rising Temperature
|
20?C
|
|
Max. Power
|
3KW(3HP)
|
|
Spindle Roundness
|
MAX?0.005mm
|
|
Lubrication
|
Grease
|
|
Net Weight
|
78kg
|
Spindle Machines Series > Spindle
Boring & Milling Spindles Units
SW-40C
SW-40C
SPECIFICATIONS
|
Model
|
SW- 40C
|
|
Spindle Bearing
|
7208-2 7207-2
|
|
Max. revolution/Minute
|
8000RPM
|
|
Rising Temperature
|
20?C
|
|
Max. Power
|
2.2KW(3HP)
|
|
Spindle Roundness
|
MAX?0.005mm
|
|
Lubrication
|
Grease
|
|
Net Weight
|
32kg
|
Spindle Machines Series > Spindle
Boring & Milling Spindles Units
SW-40 & SW-50
SW-40 / SW-40H / SW-50 / SW-50H
SPECIFICATIONS
|
Model
|
SW-40
|
SW-40H
|
SW-50
|
SW-50H
|
|
Spindle Bearing
|
32208/6208Z
-32207/6207Z
|
7208-2 7207-2
|
32010/6010Z
-32009/6009Z
|
7010-2 77009-2
|
|
Max. revolution/Minute
|
2500RPM
|
8000RPM
|
2100RPM
|
6000RPM
|
|
Rising Temperature
|
20?C
|
|
Max. Power
|
2.2KW(3HP)
|
|
Spindle Roundness
|
MAX?0.005mm
|
|
Lubrication
|
Grease
|
|
Net Weight
|
32kg
|
Spindle Machines Series > Spindle
Precision Spindles Units
SW-40G
SW-40G / SW-40GH
SPECIFICATIONS
|
Model
|
SW-40G
|
SW-40GH
|
|
Spindle Bearing
|
32208/6028Z-32207/6207Z
|
7208-2 7207-2
|
|
Max. revolution/Minute
|
2500RPM
|
8000RPM
|
|
Rising Temperature
|
20?C
|
|
Max. Power
|
2.2KW(3HP)
|
|
Spindle Roundness
|
MAX?0.005mm
|
|
Lubrication
|
Grease
|
|
Net Weight
|
35kg
|
Spindle Machines Series > Spindle
Boring & Milling Spindles Units
SW-30
SW-30 / SW-30H / SW-30C
SPECIFICATIONS
|
Model
|
SW-30
|
SW-30H
|
SW-30C
|
|
Spindle Bearing
|
32206-2 6206-2
|
7206-4
|
7200-P4-4
|
|
Max. revolution/Minute
|
3000RPM
|
10000RPM
|
12000RPM
|
|
Rising Temperature
|
20?C
|
20?C
|
SW-30C
|
|
Max. Power
|
1.5KW(2HP)
|
|
Spindle Roundness
|
MAX?0.005mm
|
|
Lubrication
|
Grease
|
|
Net Weight
|
12kg
|
Spindle Machines Series > Spindle
Boring & Milling Spindles Units
SW-20B
SW-20B / SW-20BH
SPECIFICATIONS
|
Model
|
SW-20B
|
SW-20BH
|
|
Spindle Bearing
|
32004-2 6004Z-2
|
7004-4
|
|
Max. revolution/Minute
|
6000RPM
|
10000RPM
|
|
Rising Temperature
|
20?C
|
|
Max. Power
|
0.75KW(1HP)
|
|
Spindle Roundness
|
MAX?0.005mm
|
|
Lubrication
|
Grease
|
|
Net Weight
|
10kg
|
Spindle Machines Series > Spindle
Boring & Milling Spindles Units
SW-NN60 & SW-NN80
SW-NN60 / SW-NN80
SPECIFICATIONS
|
Model
|
SW- NN60
|
SW- NN80
|
|
Spindle Bearing
|
NN3012-1 7012DB*1 NN3010
|
NN3016-1 7016DB*1 NN3014
|
|
Max. revolution/Minute
|
4000RPM
|
2000RPM
|
|
Rising Temperature
|
20?C
|
|
Max. Power
|
3.7KW(5HP)
|
|
Spindle Roundness
|
MAX?0.005mm
|
|
Lubrication
|
Grease
|
|
Net Weight
|
50kg
|
Spindle Machines Series > Spindle
Boring & Milling Spindles Units
SW-100 & SW-200
SW-100 / SW-100H / SW-120 / SW-120H
SPECIFICATIONS
|
Model
|
SW-100
|
SW-100H
|
SW-120
|
SW-120H
|
|
Spindle Bearing
|
32220-2/6220Z
|
7220-4
|
332224-2 / 6224Z-2
|
7224-4
|
|
Max. revolution/Minute
|
800RPM
|
2000RPM
|
600RPM
|
1800RPM
|
|
Rising Temperature
|
20?C
|
|
Max. Power
|
7.5KW(10HP)
|
|
Spindle Roundness
|
MAX?0.005mm
|
|
Lubrication
|
Grease
|
|
Net Weight
|
250kg
|
Mandrel Type (S)
?Output shaft is round with key.
?Connected with coupling or keyway.
?The remedy of output shaft diameter is h6.
? Apply in the periodic conveyer, or through the gear, timing belt, chain transmits to the periodic mechanism.
CHARACTER
For the automatic and laborsaving the automations or sole-machine adopt with cam indexes are popular, in general assess the roller cam index are the most stable and confident.
1. The track of the cam are grinding by five axils CNC grinder, working smoothly, precisely orientation, no slide and deflections, no tolerance accumulation.
2. The cam are high precision, no clearance, accurate position (within ±30sec),low noise, because it have special acceleration rate curve so it can rotation in high speed driver divider smoothly over 6000rpm.
3. The cam made by high-grade alloy steel, the materials are very tenacity after heat-treating with carbon infiltration, The cam immersed in the oil with output shaft cam bearing, it can reduce scratch in high speed, keep the cam lift time up to 12,000hr.
4. The structures of the roller gear cam index are very simply, reliable and trouble free.
5. Assembly in any face, easy to use.
MAIN USE
Automatic assembling machine, process machine. Packaging machine, Filler& Capper. Food process machine, Pharmaceutical machine. Printing press, Pad Printer, Screen Printer, Hot Stamping and Hot Transfer machine. Ceramic Disc Capacitor Sorter, Label machine. Semi-conductor test and sorting machine. Periodic feeder in various industrial.
HOW TO PURCHASE
1. The diameter of in/output shaft
45D. 60D. 70D. 80D. 110D. 140D
2. The shape of output shaft
S (Mandrel Type) ? F (Flange Type)? FH (Hollow Flange Type)
3. The divisional of output shaft
2 . 3 . 4 . 5 . 6 . 8 . 10 . 12 . 16 . 20 . 24 . 30 . 36 . 48 . 60
4. Movement angle of input shaft
90 . 120 . 180 . 270 . 300 (Special angle designation was accepts)
5. Input cam shaft robate
R (Dextral Cam)?L (Sinistral Cam)?Do not consider if motor can reveres.
6. Curve of cam
a. Transfigure turn (Standard)
b. Transfigure echelon
c. Transfigure uniform velocity
7. Input shaft Selection
D : Bilateral input shaft
R : Rightwards mono-input shaft
L : Leftwards mono-input shaft
8. Installation face of output shaft
reference (Fig. 3)
|
Input and output shaft rotate direct (Fig.1)
|
Select input shaft (Fig. 2)
|
| |
|
|
|
|
|
|
|
|
Select the position of set up surface. oil level. oil supply. Drain (Fig. 3)
|
| |
|
|
|
|
|
Table of Hollow Flange I.D.
|
|
Type
|
60D
|
70D
|
80D
|
110D
|
140D
|
|
LD.
|
φ16
|
φ25
|
φ30
|
φ38
|
φ50
|
| |
|
|
|
|
|
|
-
??????T?-T-108
-
??????T?-T-121
-
???A?-A-100 / A-124
-
RU-100 / RU-120 / RU-165 / RU-200 / RU-250 / RU-300
SPECIFICATIONS
|
Model
|
RU-100
|
RU-120
|
RU-165
|
RU-200
|
RU-250
|
RU-300
|
|
Collet
|
C-6, C-9
|
|
Max. Drilling Capacity (mm)
|
6/8
|
|
R.P.M.
|
1:1
|
|
Max. Range of Centers
|
100
|
120
|
165
|
200
|
250
|
300
|
|
Lowest Distance
|
18, 26
|
|
Spindle
|
2~6
|
2~6
|
2~10
|
4~12
|
4~12
|
Spindle Head Series > Adjustable Spindles Head
A-100 / A-124
SPECIFICATIONS
|
Model
|
A-100 (A-116)
|
A-124
|
A-121S
|
|
Collet
|
C-6
|
C-9, JT1
|
C-12, JT2
|
|
Max. Drilling Capacity (mm)
|
6
|
8
|
11
|
|
R.P.M.
|
1:1.35 (1:1)
|
1:1.3 (1:1)
|
1:1.3 (1:1)
|
|
Max. Range of Centers
|
100
|
124
|
124
|
|
Lowest Distance
|
18
|
26
|
28
|
|
Spindle
|
2~4
|
Spindle Head Series Adjustable Spindles Head
T-121
SPECIFICATIONS
|
Model
|
T-71
|
T-74
|
T-108
|
NT-108
|
T-121
|
T-121S
|
NT-121S
|
|
Collet
|
ND-1, NT-1
|
C-5
|
C-6, JT1
|
C-6
|
C-9, JT1
|
C-12
|
C-9, C-12
|
|
Max. Drilling Capacity
|
3
|
4
|
6
|
6
|
8
|
10
|
8, 10
|
|
R.P.M.
|
1:1
|
|
Max. Range of Centers
|
71
|
74
|
108
|
108
|
121
|
121
|
121
|
|
Lowest Distance
|
10
|
12
|
18
|
18
|
24
|
27
|
27
|
|
Spindle
|
2
|
Spindle Machines Series > Spindle
-
Boring & Milling Spindles Units-SW-20B
-
Boring & Milling Spindles Units-SW-30
-
Precision Spindles Units-SW-40G
-
Boring & Milling Spindles Units-SW-40 & SW-50
-
Boring & Milling Spindles Units-SW-40C
-
Boring & Milling Spindles Units-SW-40F
-
Boring & Milling Spindles Units-SW-60
-
Boring & Milling Spindles Units-SW-80
-
Boring & Milling Spindles Unit
Spindle Machines Series > Spindle
Boring & Milling Spindles Units
SW-85K
SW-85K
SPECIFICATIONS
|
Model
|
SW- 85K
|
|
Spindle Bearing
|
32216 / 32215 / 6215Z
|
|
Max. revolution/Minute
|
1200RPM
|
|
Rising Temperature
|
20?C
|
|
Max. Power
|
7.5KW(10HP)
|
|
Spindle Roundness
|
MAX?0.005mm
|
|
Lubrication
|
Grease
|
|
Net Weight
|
145kg
|
Spindle Machines Series > Spindle
Boring & Milling Spindles Units
SW-80
SW-80 / SW-80H
SPECIFICATIONS
|
Model
|
SW- 80
|
SW- 80H
|
|
Spindle Bearing
|
32216-2 / 6216Z-2
|
7216-4
|
|
Max. revolution/Minute
|
4000RPM
|
3000RPM
|
|
Rising Temperature
|
20?C
|
|
Max. Power
|
5.5KW(7.5HP)
|
|
Spindle Roundness
|
MAX?0.005mm
|
|
Lubrication
|
Grease
|
|
Net Weight
|
95kg
|
Spindle Machines Series > Spindle
Boring & Milling Spindles Units
SW-60
SW-60 / SW-60H
SPECIFICATIONS
|
Model
|
SW- 60
|
SW- 60H
|
|
Spindle Bearing
|
32216/6212Z-32211/6211Z
|
7212-2 7211-2
|
|
Max. revolution/Minute
|
1700RPM
|
4000RPM
|
|
Rising Temperature
|
20?C
|
|
Max. Power
|
3.7KW(5HP)
|
|
Spindle Roundness
|
MAX?0.005mm
|
|
Lubrication
|
Grease
|
|
Net Weight
|
60kg
|
Spindle Machines Series > Spindle
Boring & Milling Spindles Units
SW-40F
SW-40F / SW-40FH
SPECIFICATIONS
|
Model
|
SW- 40F
|
SW- 40FH
|
|
Spindle Bearing
|
322018/6208Z-32207/6207Z
|
7208-2 7207-2
|
|
Max. revolution/Minute
|
2500RPM
|
8000RPM
|
|
Rising Temperature
|
20?C
|
|
Max. Power
|
3KW(3HP)
|
|
Spindle Roundness
|
MAX?0.005mm
|
|
Lubrication
|
Grease
|
|
Net Weight
|
78kg
|
Spindle Machines Series > Spindle
Boring & Milling Spindles Units
SW-40C
SW-40C
SPECIFICATIONS
|
Model
|
SW- 40C
|
|
Spindle Bearing
|
7208-2 7207-2
|
|
Max. revolution/Minute
|
8000RPM
|
|
Rising Temperature
|
20?C
|
|
Max. Power
|
2.2KW(3HP)
|
|
Spindle Roundness
|
MAX?0.005mm
|
|
Lubrication
|
Grease
|
|
Net Weight
|
32kg
|
Spindle Machines Series > Spindle
Boring & Milling Spindles Units
SW-40 & SW-50
SW-40 / SW-40H / SW-50 / SW-50H
SPECIFICATIONS
|
Model
|
SW-40
|
SW-40H
|
SW-50
|
SW-50H
|
|
Spindle Bearing
|
32208/6208Z
-32207/6207Z
|
7208-2 7207-2
|
32010/6010Z
-32009/6009Z
|
7010-2 77009-2
|
|
Max. revolution/Minute
|
2500RPM
|
8000RPM
|
2100RPM
|
6000RPM
|
|
Rising Temperature
|
20?C
|
|
Max. Power
|
2.2KW(3HP)
|
|
Spindle Roundness
|
MAX?0.005mm
|
|
Lubrication
|
Grease
|
|
Net Weight
|
32kg
|
Spindle Machines Series > Spindle
Precision Spindles Units
SW-40G
SW-40G / SW-40GH
SPECIFICATIONS
|
Model
|
SW-40G
|
SW-40GH
|
|
Spindle Bearing
|
32208/6028Z-32207/6207Z
|
7208-2 7207-2
|
|
Max. revolution/Minute
|
2500RPM
|
8000RPM
|
|
Rising Temperature
|
20?C
|
|
Max. Power
|
2.2KW(3HP)
|
|
Spindle Roundness
|
MAX?0.005mm
|
|
Lubrication
|
Grease
|
|
Net Weight
|
35kg
|
Spindle Machines Series > Spindle
Boring & Milling Spindles Units
SW-30
SW-30 / SW-30H / SW-30C
SPECIFICATIONS
|
Model
|
SW-30
|
SW-30H
|
SW-30C
|
|
Spindle Bearing
|
32206-2 6206-2
|
7206-4
|
7200-P4-4
|
|
Max. revolution/Minute
|
3000RPM
|
10000RPM
|
12000RPM
|
|
Rising Temperature
|
20?C
|
20?C
|
SW-30C
|
|
Max. Power
|
1.5KW(2HP)
|
|
Spindle Roundness
|
MAX?0.005mm
|
|
Lubrication
|
Grease
|
|
Net Weight
|
12kg
|
Spindle Machines Series > Spindle
Boring & Milling Spindles Units
SW-20B
SW-20B / SW-20BH
SPECIFICATIONS
|
Model
|
SW-20B
|
SW-20BH
|
|
Spindle Bearing
|
32004-2 6004Z-2
|
7004-4
|
|
Max. revolution/Minute
|
6000RPM
|
10000RPM
|
|
Rising Temperature
|
20?C
|
|
Max. Power
|
0.75KW(1HP)
|
|
Spindle Roundness
|
MAX?0.005mm
|
|
Lubrication
|
Grease
|
|
Net Weight
|
10kg
|
Spindle Machines Series > Spindle
Boring & Milling Spindles Units
SW-NN60 & SW-NN80
SW-NN60 / SW-NN80
SPECIFICATIONS
|
Model
|
SW- NN60
|
SW- NN80
|
|
Spindle Bearing
|
NN3012-1 7012DB*1 NN3010
|
NN3016-1 7016DB*1 NN3014
|
|
Max. revolution/Minute
|
4000RPM
|
2000RPM
|
|
Rising Temperature
|
20?C
|
|
Max. Power
|
3.7KW(5HP)
|
|
Spindle Roundness
|
MAX?0.005mm
|
|
Lubrication
|
Grease
|
|
Net Weight
|
50kg
|
Spindle Machines Series > Spindle
Boring & Milling Spindles Units
SW-100 & SW-200
SW-100 / SW-100H / SW-120 / SW-120H
SPECIFICATIONS
|
Model
|
SW-100
|
SW-100H
|
SW-120
|
SW-120H
|
|
Spindle Bearing
|
32220-2/6220Z
|
7220-4
|
332224-2 / 6224Z-2
|
7224-4
|
|
Max. revolution/Minute
|
800RPM
|
2000RPM
|
600RPM
|
1800RPM
|
|
Rising Temperature
|
20?C
|
|
Max. Power
|
7.5KW(10HP)
|
|
Spindle Roundness
|
MAX?0.005mm
|
|
Lubrication
|
Grease
|
|
Net Weight
|
250kg
|
Mandrel Type (S)
?Output shaft is round with key.
?Connected with coupling or keyway.
?The remedy of output shaft diameter is h6.
? Apply in the periodic conveyer, or through the gear, timing belt, chain transmits to the periodic mechanism.
CHARACTER
For the automatic and laborsaving the automations or sole-machine adopt with cam indexes are popular, in general assess the roller cam index are the most stable and confident.
1. The track of the cam are grinding by five axils CNC grinder, working smoothly, precisely orientation, no slide and deflections, no tolerance accumulation.
2. The cam are high precision, no clearance, accurate position (within ±30sec),low noise, because it have special acceleration rate curve so it can rotation in high speed driver divider smoothly over 6000rpm.
3. The cam made by high-grade alloy steel, the materials are very tenacity after heat-treating with carbon infiltration, The cam immersed in the oil with output shaft cam bearing, it can reduce scratch in high speed, keep the cam lift time up to 12,000hr.
4. The structures of the roller gear cam index are very simply, reliable and trouble free.
5. Assembly in any face, easy to use.
MAIN USE
Automatic assembling machine, process machine. Packaging machine, Filler& Capper. Food process machine, Pharmaceutical machine. Printing press, Pad Printer, Screen Printer, Hot Stamping and Hot Transfer machine. Ceramic Disc Capacitor Sorter, Label machine. Semi-conductor test and sorting machine. Periodic feeder in various industrial.
HOW TO PURCHASE
1. The diameter of in/output shaft
45D. 60D. 70D. 80D. 110D. 140D
2. The shape of output shaft
S (Mandrel Type) ? F (Flange Type)? FH (Hollow Flange Type)
3. The divisional of output shaft
2 . 3 . 4 . 5 . 6 . 8 . 10 . 12 . 16 . 20 . 24 . 30 . 36 . 48 . 60
4. Movement angle of input shaft
90 . 120 . 180 . 270 . 300 (Special angle designation was accepts)
5. Input cam shaft robate
R (Dextral Cam)?L (Sinistral Cam)?Do not consider if motor can reveres.
6. Curve of cam
a. Transfigure turn (Standard)
b. Transfigure echelon
c. Transfigure uniform velocity
7. Input shaft Selection
D : Bilateral input shaft
R : Rightwards mono-input shaft
L : Leftwards mono-input shaft
8. Installation face of output shaft
reference (Fig. 3)
|
Input and output shaft rotate direct (Fig.1)
|
Select input shaft (Fig. 2)
|
| |
|
|
|
|
|
|
|
|
Select the position of set up surface. oil level. oil supply. Drain (Fig. 3)
|
| |
|
|
|
|
|
Table of Hollow Flange I.D.
|
|
Type
|
60D
|
70D
|
80D
|
110D
|
140D
|
|
LD.
|
φ16
|
φ25
|
φ30
|
φ38
|
φ50
|
| |
|
|
|
|
|
|
-
??????T?-T-108
-
??????T?-T-121
-
???A?-A-100 / A-124
-
RU-100 / RU-120 / RU-165 / RU-200 / RU-250 / RU-300
SPECIFICATIONS
|
Model
|
RU-100
|
RU-120
|
RU-165
|
RU-200
|
RU-250
|
RU-300
|
|
Collet
|
C-6, C-9
|
|
Max. Drilling Capacity (mm)
|
6/8
|
|
R.P.M.
|
1:1
|
|
Max. Range of Centers
|
100
|
120
|
165
|
200
|
250
|
300
|
|
Lowest Distance
|
18, 26
|
|
Spindle
|
2~6
|
2~6
|
2~10
|
4~12
|
4~12
|
Spindle Head Series > Adjustable Spindles Head
A-100 / A-124
SPECIFICATIONS
|
Model
|
A-100 (A-116)
|
A-124
|
A-121S
|
|
Collet
|
C-6
|
C-9, JT1
|
C-12, JT2
|
|
Max. Drilling Capacity (mm)
|
6
|
8
|
11
|
|
R.P.M.
|
1:1.35 (1:1)
|
1:1.3 (1:1)
|
1:1.3 (1:1)
|
|
Max. Range of Centers
|
100
|
124
|
124
|
|
Lowest Distance
|
18
|
26
|
28
|
|
Spindle
|
2~4
|
Spindle Head Series Adjustable Spindles Head
T-121
SPECIFICATIONS
|
Model
|
T-71
|
T-74
|
T-108
|
NT-108
|
T-121
|
T-121S
|
NT-121S
|
|
Collet
|
ND-1, NT-1
|
C-5
|
C-6, JT1
|
C-6
|
C-9, JT1
|
C-12
|
C-9, C-12
|
|
Max. Drilling Capacity
|
3
|
4
|
6
|
6
|
8
|
10
|
8, 10
|
|
R.P.M.
|
1:1
|
|
Max. Range of Centers
|
71
|
74
|
108
|
108
|
121
|
121
|
121
|
|
Lowest Distance
|
10
|
12
|
18
|
18
|
24
|
27
|
27
|
|
Spindle
|
2
|
Spindle Machines Series > Spindle
-
Boring & Milling Spindles Units-SW-20B
-
Boring & Milling Spindles Units-SW-30
-
Precision Spindles Units-SW-40G
-
Boring & Milling Spindles Units-SW-40 & SW-50
-
Boring & Milling Spindles Units-SW-40C
-
Boring & Milling Spindles Units-SW-40F
-
Boring & Milling Spindles Units-SW-60
-
Boring & Milling Spindles Units-SW-80
-
Boring & Milling Spindles Unit
Spindle Machines Series > Spindle
Boring & Milling Spindles Units
SW-85K
SW-85K
SPECIFICATIONS
|
Model
|
SW- 85K
|
|
Spindle Bearing
|
32216 / 32215 / 6215Z
|
|
Max. revolution/Minute
|
1200RPM
|
|
Rising Temperature
|
20?C
|
|
Max. Power
|
7.5KW(10HP)
|
|
Spindle Roundness
|
MAX?0.005mm
|
|
Lubrication
|
Grease
|
|
Net Weight
|
145kg
|
Spindle Machines Series > Spindle
Boring & Milling Spindles Units
SW-80
SW-80 / SW-80H
SPECIFICATIONS
|
Model
|
SW- 80
|
SW- 80H
|
|
Spindle Bearing
|
32216-2 / 6216Z-2
|
7216-4
|
|
Max. revolution/Minute
|
4000RPM
|
3000RPM
|
|
Rising Temperature
|
20?C
|
|
Max. Power
|
5.5KW(7.5HP)
|
|
Spindle Roundness
|
MAX?0.005mm
|
|
Lubrication
|
Grease
|
|
Net Weight
|
95kg
|
Spindle Machines Series > Spindle
Boring & Milling Spindles Units
SW-60
SW-60 / SW-60H
SPECIFICATIONS
|
Model
|
SW- 60
|
SW- 60H
|
|
Spindle Bearing
|
32216/6212Z-32211/6211Z
|
7212-2 7211-2
|
|
Max. revolution/Minute
|
1700RPM
|
4000RPM
|
|
Rising Temperature
|
20?C
|
|
Max. Power
|
3.7KW(5HP)
|
|
Spindle Roundness
|
MAX?0.005mm
|
|
Lubrication
|
Grease
|
|
Net Weight
|
60kg
|
Spindle Machines Series > Spindle
Boring & Milling Spindles Units
SW-40F
SW-40F / SW-40FH
SPECIFICATIONS
|
Model
|
SW- 40F
|
SW- 40FH
|
|
Spindle Bearing
|
322018/6208Z-32207/6207Z
|
7208-2 7207-2
|
|
Max. revolution/Minute
|
2500RPM
|
8000RPM
|
|
Rising Temperature
|
20?C
|
|
Max. Power
|
3KW(3HP)
|
|
Spindle Roundness
|
MAX?0.005mm
|
|
Lubrication
|
Grease
|
|
Net Weight
|
78kg
|
Spindle Machines Series > Spindle
Boring & Milling Spindles Units
SW-40C
SW-40C
SPECIFICATIONS
|
Model
|
SW- 40C
|
|
Spindle Bearing
|
7208-2 7207-2
|
|
Max. revolution/Minute
|
8000RPM
|
|
Rising Temperature
|
20?C
|
|
Max. Power
|
2.2KW(3HP)
|
|
Spindle Roundness
|
MAX?0.005mm
|
|
Lubrication
|
Grease
|
|
Net Weight
|
32kg
|
Spindle Machines Series > Spindle
Boring & Milling Spindles Units
SW-40 & SW-50
SW-40 / SW-40H / SW-50 / SW-50H
SPECIFICATIONS
|
Model
|
SW-40
|
SW-40H
|
SW-50
|
SW-50H
|
|
Spindle Bearing
|
32208/6208Z
-32207/6207Z
|
7208-2 7207-2
|
32010/6010Z
-32009/6009Z
|
7010-2 77009-2
|
|
Max. revolution/Minute
|
2500RPM
|
8000RPM
|
2100RPM
|
6000RPM
|
|
Rising Temperature
|
20?C
|
|
Max. Power
|
2.2KW(3HP)
|
|
Spindle Roundness
|
MAX?0.005mm
|
|
Lubrication
|
Grease
|
|
Net Weight
|
32kg
|
Spindle Machines Series > Spindle
Precision Spindles Units
SW-40G
SW-40G / SW-40GH
SPECIFICATIONS
|
Model
|
SW-40G
|
SW-40GH
|
|
Spindle Bearing
|
32208/6028Z-32207/6207Z
|
7208-2 7207-2
|
|
Max. revolution/Minute
|
2500RPM
|
8000RPM
|
|
Rising Temperature
|
20?C
|
|
Max. Power
|
2.2KW(3HP)
|
|
Spindle Roundness
|
MAX?0.005mm
|
|
Lubrication
|
Grease
|
|
Net Weight
|
35kg
|
Spindle Machines Series > Spindle
Boring & Milling Spindles Units
SW-30
SW-30 / SW-30H / SW-30C
SPECIFICATIONS
|
Model
|
SW-30
|
SW-30H
|
SW-30C
|
|
Spindle Bearing
|
32206-2 6206-2
|
7206-4
|
7200-P4-4
|
|
Max. revolution/Minute
|
3000RPM
|
10000RPM
|
12000RPM
|
|
Rising Temperature
|
20?C
|
20?C
|
SW-30C
|
|
Max. Power
|
1.5KW(2HP)
|
|
Spindle Roundness
|
MAX?0.005mm
|
|
Lubrication
|
Grease
|
|
Net Weight
|
12kg
|
Spindle Machines Series > Spindle
Boring & Milling Spindles Units
SW-20B
SW-20B / SW-20BH
SPECIFICATIONS
|
Model
|
SW-20B
|
SW-20BH
|
|
Spindle Bearing
|
32004-2 6004Z-2
|
7004-4
|
|
Max. revolution/Minute
|
6000RPM
|
10000RPM
|
|
Rising Temperature
|
20?C
|
|
Max. Power
|
0.75KW(1HP)
|
|
Spindle Roundness
|
MAX?0.005mm
|
|
Lubrication
|
Grease
|
|
Net Weight
|
10kg
|
Spindle Machines Series > Spindle
Boring & Milling Spindles Units
SW-NN60 & SW-NN80
SW-NN60 / SW-NN80
SPECIFICATIONS
|
Model
|
SW- NN60
|
SW- NN80
|
|
Spindle Bearing
|
NN3012-1 7012DB*1 NN3010
|
NN3016-1 7016DB*1 NN3014
|
|
Max. revolution/Minute
|
4000RPM
|
2000RPM
|
|
Rising Temperature
|
20?C
|
|
Max. Power
|
3.7KW(5HP)
|
|
Spindle Roundness
|
MAX?0.005mm
|
|
Lubrication
|
Grease
|
|
Net Weight
|
50kg
|
Spindle Machines Series > Spindle
สายด่วน 098-4288648
โทร : คุณภูรินทร์ 0984288648
Boring & Milling Spindles Units
SW-100 & SW-200
SW-100 / SW-100H / SW-120 / SW-120H
SPECIFICATIONS
|
Model
|
SW-100
|
SW-100H
|
SW-120
|
SW-120H
|
|
Spindle Bearing
|
32220-2/6220Z
|
7220-4
|
332224-2 / 6224Z-2
|
7224-4
|
|
Max. revolution/Minute
|
800RPM
|
2000RPM
|
600RPM
|
1800RPM
|
|
Rising Temperature
|
20?C
|
|
Max. Power
|
7.5KW(10HP)
|
|
Spindle Roundness
|
MAX?0.005mm
|
|
Lubrication
|
Grease
|
|
Net Weight
|
250kg
|
Mandrel Type (S)
?Output shaft is round with key.
?Connected with coupling or keyway.
?The remedy of output shaft diameter is h6.
? Apply in the periodic conveyer, or through the gear, timing belt, chain transmits to the periodic mechanism.
CHARACTER
For the automatic and laborsaving the automations or sole-machine adopt with cam indexes are popular, in general assess the roller cam index are the most stable and confident.
1. The track of the cam are grinding by five axils CNC grinder, working smoothly, precisely orientation, no slide and deflections, no tolerance accumulation.
2. The cam are high precision, no clearance, accurate position (within ±30sec),low noise, because it have special acceleration rate curve so it can rotation in high speed driver divider smoothly over 6000rpm.
3. The cam made by high-grade alloy steel, the materials are very tenacity after heat-treating with carbon infiltration, The cam immersed in the oil with output shaft cam bearing, it can reduce scratch in high speed, keep the cam lift time up to 12,000hr.
4. The structures of the roller gear cam index are very simply, reliable and trouble free.
5. Assembly in any face, easy to use.
MAIN USE
Automatic assembling machine, process machine. Packaging machine, Filler& Capper. Food process machine, Pharmaceutical machine. Printing press, Pad Printer, Screen Printer, Hot Stamping and Hot Transfer machine. Ceramic Disc Capacitor Sorter, Label machine. Semi-conductor test and sorting machine. Periodic feeder in various industrial.
HOW TO PURCHASE
1. The diameter of in/output shaft
45D. 60D. 70D. 80D. 110D. 140D
2. The shape of output shaft
S (Mandrel Type) ? F (Flange Type)? FH (Hollow Flange Type)
3. The divisional of output shaft
2 . 3 . 4 . 5 . 6 . 8 . 10 . 12 . 16 . 20 . 24 . 30 . 36 . 48 . 60
4. Movement angle of input shaft
90 . 120 . 180 . 270 . 300 (Special angle designation was accepts)
5. Input cam shaft robate
R (Dextral Cam)?L (Sinistral Cam)?Do not consider if motor can reveres.
6. Curve of cam
a. Transfigure turn (Standard)
b. Transfigure echelon
c. Transfigure uniform velocity
7. Input shaft Selection
D : Bilateral input shaft
R : Rightwards mono-input shaft
L : Leftwards mono-input shaft
8. Installation face of output shaft
reference (Fig. 3)
|
Input and output shaft rotate direct (Fig.1)
|
Select input shaft (Fig. 2)
|
| |
|
|
|
|
|
|
|
|
Select the position of set up surface. oil level. oil supply. Drain (Fig. 3)
|
| |
|
|
|
|
|
Table of Hollow Flange I.D.
|
|
Type
|
60D
|
70D
|
80D
|
110D
|
140D
|
|
LD.
|
φ16
|
φ25
|
φ30
|
φ38
|
φ50
|
| |
|
|
|
|
|
|
-
??????T?-T-108
-
??????T?-T-121
-
???A?-A-100 / A-124
-
RU-100 / RU-120 / RU-165 / RU-200 / RU-250 / RU-300
SPECIFICATIONS
|
Model
|
RU-100
|
RU-120
|
RU-165
|
RU-200
|
RU-250
|
RU-300
|
|
Collet
|
C-6, C-9
|
|
Max. Drilling Capacity (mm)
|
6/8
|
|
R.P.M.
|
1:1
|
|
Max. Range of Centers
|
100
|
120
|
165
|
200
|
250
|
300
|
|
Lowest Distance
|
18, 26
|
|
Spindle
|
2~6
|
2~6
|
2~10
|
4~12
|
4~12
|
Spindle Head Series > Adjustable Spindles Head
A-100 / A-124
SPECIFICATIONS
|
Model
|
A-100 (A-116)
|
A-124
|
A-121S
|
|
Collet
|
C-6
|
C-9, JT1
|
C-12, JT2
|
|
Max. Drilling Capacity (mm)
|
6
|
8
|
11
|
|
R.P.M.
|
1:1.35 (1:1)
|
1:1.3 (1:1)
|
1:1.3 (1:1)
|
|
Max. Range of Centers
|
100
|
124
|
124
|
|
Lowest Distance
|
18
|
26
|
28
|
|
Spindle
|
2~4
|
Spindle Head Series Adjustable Spindles Head
T-121
SPECIFICATIONS
|
Model
|
T-71
|
T-74
|
T-108
|
NT-108
|
T-121
|
T-121S
|
NT-121S
|
|
Collet
|
ND-1, NT-1
|
C-5
|
C-6, JT1
|
C-6
|
C-9, JT1
|
C-12
|
C-9, C-12
|
|
Max. Drilling Capacity
|
3
|
4
|
6
|
6
|
8
|
10
|
8, 10
|
|
R.P.M.
|
1:1
|
|
Max. Range of Centers
|
71
|
74
|
108
|
108
|
121
|
121
|
121
|
|
Lowest Distance
|
10
|
12
|
18
|
18
|
24
|
27
|
27
|
|
Spindle
|
2
|
Spindle Machines Series > Spindle
-
Boring & Milling Spindles Units-SW-20B
-
Boring & Milling Spindles Units-SW-30
-
Precision Spindles Units-SW-40G
-
Boring & Milling Spindles Units-SW-40 & SW-50
-
Boring & Milling Spindles Units-SW-40C
-
Boring & Milling Spindles Units-SW-40F
-
Boring & Milling Spindles Units-SW-60
-
Boring & Milling Spindles Units-SW-80
-
Boring & Milling Spindles Unit
Spindle Machines Series > Spindle
Boring & Milling Spindles Units
SW-85K
SW-85K
SPECIFICATIONS
|
Model
|
SW- 85K
|
|
Spindle Bearing
|
32216 / 32215 / 6215Z
|
|
Max. revolution/Minute
|
1200RPM
|
|
Rising Temperature
|
20?C
|
|
Max. Power
|
7.5KW(10HP)
|
|
Spindle Roundness
|
MAX?0.005mm
|
|
Lubrication
|
Grease
|
|
Net Weight
|
145kg
|
Spindle Machines Series > Spindle
Boring & Milling Spindles Units
SW-80
SW-80 / SW-80H
SPECIFICATIONS
|
Model
|
SW- 80
|
SW- 80H
|
|
Spindle Bearing
|
32216-2 / 6216Z-2
|
7216-4
|
|
Max. revolution/Minute
|
4000RPM
|
3000RPM
|
|
Rising Temperature
|
20?C
|
|
Max. Power
|
5.5KW(7.5HP)
|
|
Spindle Roundness
|
MAX?0.005mm
|
|
Lubrication
|
Grease
|
|
Net Weight
|
95kg
|
Spindle Machines Series > Spindle
Boring & Milling Spindles Units
SW-60
SW-60 / SW-60H
SPECIFICATIONS
|
Model
|
SW- 60
|
SW- 60H
|
|
Spindle Bearing
|
32216/6212Z-32211/6211Z
|
7212-2 7211-2
|
|
Max. revolution/Minute
|
1700RPM
|
4000RPM
|
|
Rising Temperature
|
20?C
|
|
Max. Power
|
3.7KW(5HP)
|
|
Spindle Roundness
|
MAX?0.005mm
|
|
Lubrication
|
Grease
|
|
Net Weight
|
60kg
|
Spindle Machines Series > Spindle
Boring & Milling Spindles Units
SW-40F
SW-40F / SW-40FH
SPECIFICATIONS
|
Model
|
SW- 40F
|
SW- 40FH
|
|
Spindle Bearing
|
322018/6208Z-32207/6207Z
|
7208-2 7207-2
|
|
Max. revolution/Minute
|
2500RPM
|
8000RPM
|
|
Rising Temperature
|
20?C
|
|
Max. Power
|
3KW(3HP)
|
|
Spindle Roundness
|
MAX?0.005mm
|
|
Lubrication
|
Grease
|
|
Net Weight
|
78kg
|
Spindle Machines Series > Spindle
Boring & Milling Spindles Units
SW-40C
SW-40C
SPECIFICATIONS
|
Model
|
SW- 40C
|
|
Spindle Bearing
|
7208-2 7207-2
|
|
Max. revolution/Minute
|
8000RPM
|
|
Rising Temperature
|
20?C
|
|
Max. Power
|
2.2KW(3HP)
|
|
Spindle Roundness
|
MAX?0.005mm
|
|
Lubrication
|
Grease
|
|
Net Weight
|
32kg
|
Spindle Machines Series > Spindle
Boring & Milling Spindles Units
SW-40 & SW-50
SW-40 / SW-40H / SW-50 / SW-50H
SPECIFICATIONS
|
Model
|
SW-40
|
SW-40H
|
SW-50
|
SW-50H
|
|
Spindle Bearing
|
32208/6208Z
-32207/6207Z
|
7208-2 7207-2
|
32010/6010Z
-32009/6009Z
|
7010-2 77009-2
|
|
Max. revolution/Minute
|
2500RPM
|
8000RPM
|
2100RPM
|
6000RPM
|
|
Rising Temperature
|
20?C
|
|
Max. Power
|
2.2KW(3HP)
|
|
Spindle Roundness
|
MAX?0.005mm
|
|
Lubrication
|
Grease
|
|
Net Weight
|
32kg
|
Spindle Machines Series > Spindle
Precision Spindles Units
SW-40G
SW-40G / SW-40GH
SPECIFICATIONS
|
Model
|
SW-40G
|
SW-40GH
|
|
Spindle Bearing
|
32208/6028Z-32207/6207Z
|
7208-2 7207-2
|
|
Max. revolution/Minute
|
2500RPM
|
8000RPM
|
|
Rising Temperature
|
20?C
|
|
Max. Power
|
2.2KW(3HP)
|
|
Spindle Roundness
|
MAX?0.005mm
|
|
Lubrication
|
Grease
|
|
Net Weight
|
35kg
|
Spindle Machines Series > Spindle
Boring & Milling Spindles Units
SW-30
SW-30 / SW-30H / SW-30C
SPECIFICATIONS
|
Model
|
SW-30
|
SW-30H
|
SW-30C
|
|
Spindle Bearing
|
32206-2 6206-2
|
7206-4
|
7200-P4-4
|
|
Max. revolution/Minute
|
3000RPM
|
10000RPM
|
12000RPM
|
|
Rising Temperature
|
20?C
|
20?C
|
SW-30C
|
|
Max. Power
|
1.5KW(2HP)
|
|
Spindle Roundness
|
MAX?0.005mm
|
|
Lubrication
|
Grease
|
|
Net Weight
|
12kg
|
Spindle Machines Series > Spindle
Boring & Milling Spindles Units
SW-20B
SW-20B / SW-20BH
SPECIFICATIONS
|
Model
|
SW-20B
|
SW-20BH
|
|
Spindle Bearing
|
32004-2 6004Z-2
|
7004-4
|
|
Max. revolution/Minute
|
6000RPM
|
10000RPM
|
|
Rising Temperature
|
20?C
|
|
Max. Power
|
0.75KW(1HP)
|
|
Spindle Roundness
|
MAX?0.005mm
|
|
Lubrication
|
Grease
|
|
Net Weight
|
10kg
|
Spindle Machines Series > Spindle
Boring & Milling Spindles Units
SW-NN60 & SW-NN80
SW-NN60 / SW-NN80
SPECIFICATIONS
|
Model
|
SW- NN60
|
SW- NN80
|
|
Spindle Bearing
|
NN3012-1 7012DB*1 NN3010
|
NN3016-1 7016DB*1 NN3014
|
|
Max. revolution/Minute
|
4000RPM
|
2000RPM
|
|
Rising Temperature
|
20?C
|
|
Max. Power
|
3.7KW(5HP)
|
|
Spindle Roundness
|
MAX?0.005mm
|
|
Lubrication
|
Grease
|
|
Net Weight
|
50kg
|
Spindle Machines Series > Spindle
สายด่วน 098-4288648
โทร : คุณภูรินทร์ 0984288648
Boring & Milling Spindles Units
SW-100 & SW-200
SW-100 / SW-100H / SW-120 / SW-120H
SPECIFICATIONS
|
Model
|
SW-100
|
SW-100H
|
SW-120
|
SW-120H
|
|
Spindle Bearing
|
32220-2/6220Z
|
7220-4
|
332224-2 / 6224Z-2
|
7224-4
|
|
Max. revolution/Minute
|
800RPM
|
2000RPM
|
600RPM
|
1800RPM
|
|
Rising Temperature
|
20?C
|
|
Max. Power
|
7.5KW(10HP)
|
|
Spindle Roundness
|
MAX?0.005mm
|
|
Lubrication
|
Grease
|
|
Net Weight
|
250kg
|
|
Sales Engineer
098-4288648
เก็บเป็นหน้าที่ใช้บ่อย
ตั้งเป็นหน้าแรก
